Chromateq

CLUB-E 1024 / PRONET-E

ETHERNET TO DMX INTERFACE

Ideal for all users, experienced lighting professionals and demanding projects, CLUB-E excels at live show control, audio and video timeline synchronization, and precise sound to light automation, using the PRO DMX 2 Chromateq software that transforms any computer into a powerful lighting control console. With a memory capacity, you can also use the CLUB-E in stand Alone application and use it with the Wi-Light 2 App when connected to a WIFI router.

PRONET-E is designed for demanding projects requiring a large number of DMX/Art-Net channels. The softwares offer up to 24-hour Audio and Video Timeline synchronization, Midi Time Code, PC Clock triggers, and Live Timeline Record (on the fly). Connected to your computer you can unlock from the software several Art-Net universes that will be sent out through the computer network card.

Newly designed aluminium housing with beautiful brushed anodized finish and updated electronics that work with all the latest 2022 Chromateq software PROD DMX 2 and PIXXEM. (as well as older versions of LED Player and Pro DMX).

RJ45 connector

USB-C
5V. DC, 0.2A

Button
NEXT scene or NODE mode selection (hold 5s)

Infrared receiver LED Infrared remote not included, optional
Icone Ethernet

Ethernet LAN / WLAN

Easy and fast communication anywhere on Local Network with DHCP or static IP addressing
Ethernet jack for wireless control over WiFi via routers

Icon Node

Art-Net, sACN to DMX NODE

Easy Art-Net/sACN-to-DMX decoding/conversion/node functionality in a single device (no need for a separate decoder) and compatible with any data source

Icon timeline

Unlock Universes and Timelines

Manage Artnet/sACN universes via the Ethernet port of the computer network card or adapter. Unlock up to 30 minutes of Audio, Video timeline synchronization

icon design

Beautiful redesigned housing

DMX IN/OUT port ruggedly built into a new sleek stackable modular aluminium design

Icon guarranty

International Warranty

5 year warranty with lifetime free software updates

Compatible Software

The new Club-E 1024 is compatible with all Chromateq software, it can be integrated into scalable control systems designed for live performance or fixed installation, or deployed individually without a computer as an elegantly simple but sophisticated standalone control solution.

All our Lighting Management Software are Free and require a Chromateq™ Device or Interface to transform your computer into an impressively adaptable and effective DMX Controller.

Main Features

Hardware & DMX (Software & Live)

CLUB-E 1024

PRONET-E

PRICE

Contact a reseller

Contact a reseller

PRO DMX 2, PIXXEM (DMX Channels)

1024 (2x512 - In/Out, 2U.)

International Warranty

5 Years

Ethernet (10 Mb/s)

Yes (LAN, compatible with Wifi router)

USB-C

Yes (5V. DC, 0.2A)

Max interface connected

12 (USB - 24 DMX) / 128 (Ethernet - 256 DMX)

RDM (Remote Device Management, bi-directional DMX)

Yes, with Pro DMX 2 only

Dimensions (mm / in)

H: 90 (3.54), W: 80 (3.15), D: 45 (1.77)

Weight / Operating Temperature / Certification

0.19 Kg (0.42 lb) / -40 to +85 C° / CE, RoHS

Stand Alone

DMX Out (16-bit channels)

1024 (2x512, 2U.)

Zone (Scene play a time)

1

NODE (Art-Net & sACN to DMX decoder / convertor)

2x512 Out per interface

Wi-Light 2 APP Remote, Commands, Configuration

Yes (LAN)

Power

5V. DC, 0.25A input by USB-C

Memory (Stand Alone)

Memory Step capacity

100 ~ 1024 (300 Kb)

Max Scene capacity

512

Triggers (Stand Alone)

Infrared remote (play/stop, pause, dimmer, speed)

Not included, need to order

Button

NEXT scene and mode selection (hold 5s)

Wi-Light 2 APP / API

Yes (LAN)

UDP protocol (3rd part software from our SDK)

Yes, Ethernet triggers and commands

Software Options

Software

CLUB-E 1024

PRONET-E

PRO DMX 2, PIXXEM, STUDIO (DMX channels)

2x512 per connected interface (In/Out)

Audio, Video Timeline (PRO DMX 2, PIXXEM)

30 mns

24h

WI-LIGHT 2 - Mobile APP / API

Software and device control from LAN

Worldwide Technical Support

Yes, English, French, Chinese​

Art-Net, sACN, DVI, DMX in/Out

ART-NET, sACN Output (PRO DMX 2)

2x512 per connected devices

16x512

ART-NET, sACN Output (PIXXEM)

8x512 per connected devices

64x512

DVI supported resolution (PIXXEM)

128x128 / 16 384 pixels

1024*768 / 786432 pixels

ART-NET, sACN Input, control, triggers, record

No

Yes

DMX Input, control, triggers, record​

Yes

Triggers

MIDI, RS232, DMX IN, Keyboard, Hyperlinks

Yes

MIDI control, Audio BEAT, BPM, Wi-Light 2, UDP

Yes

PC Clock and Calendar, MTC, SMPTE

No

Yes

Live Timeline Recording + Multiple Timeline

No

Yes

User Interface customization

Yes

Audio, Video timeline synchronization

Yes, 30 minutes

Yes, 24 hours
